Preset 220K (ohm) Variable Resistor – Metal (EP085)
₹6.00 (Price is Exclusive of GST)
Specifications
Track Resistance: 220K ohm
No. of Turns: 1
Resistance Tolerance: ± 10%
Temperature Coefficient: ± 100ppm/°C
Potentiometer Mounting: Through Hole
Adjustment Type: Top
Contact Resistance Variation +: 1%
Full Power Rating Temperature: 85°C
Lead Diameter: 0.5mm
Operating Temperature Range: -55°C to +125°C
Resistance: 220kohm
Resistor Element Material: Variable Metal Preset
Description
Preset 220K (ohm) Variable Resistor
Preset 220K (ohm) (Variable Resistance)
This adjustable or Variable resistor is PCB mountable and has 3 terminals. The voltage between the terminal varies as the preset is rotated.
The variable resistors are used for variating voltage as per the need in a circuit. The outer two pins are connected to Vcc and 0V, and the center pin outputs a variable voltage between 0V and Vcc as the potentiometer is rotated.
